XT-818 Controllable Coil Leads with Fully Automatic Voice Coil Winding Machine for speaker production
Product Features
The automatic winding machine utilizes an advanced high-precision motion controller for high-precision linear positioning and arc interpolation positioning. It offers long life, programmable features, and more to ensure high efficiency and precision, with minimal deformation to enhance product quality. Additionally, it can be customized to design and wind special coils according to customer needs.
Equipment Overview
This fully automatic high-precision winding machine is specifically designed to provide controllable coil leads for fully automatic production lines. It can control the coil leads from any angle and position, with automatic winding, wire feeding, stretching, flipping, lead wire bending, fixture placement, and waste material collection. These features greatly enhance the efficiency of fully automatic production.
Application areas
1511, 1206, 1506 and 1609 speaker voice coils, air core coils, and special-shaped coils are suitable for fully automatic assembly and supporting production lines.
Product parameters
| Model | XT-818 | Spindles | 18 spindles |
| Machine dimension: | 880(W)×1900(L)×1800(H)mm | winding speed | ≤4000rpm |
| G. W: | 600KG | wire size | 0.018-0.2(mm) |
| Power supply: | AC220V,50/60Hz | coil stack height | ≤8mm |
| Power: | 3KW | coil outer diameter | ≤30mm(can customize) |
| Air pressure: | 0.4Mpa～0.7Mpa | lead wire position | from any angle |
| spindle direction of rotation | Clockwise/counterclockwise | lead wire length | 40-80mm(Clockwise/counterclockwise) |
| Controller | touch screen | Wire cutting mode | Custom blade cutting |
| Number of spindles | 18 spindles | tensioner | servo tensioner |
| Production capacity | 300-550pcs /H |
